Positive Displacement Cast Iron Roots Type Air Blower For Ash Blowing In Power Plant

Positive Displacement Cast Iron Roots Type Air Blower For Ash Blowing In Power Plant

  • Positive Displacement Cast Iron Roots Type Air Blower For Ash Blowing In Power Plant
Positive Displacement Cast Iron Roots Type Air Blower For Ash Blowing In Power Plant
Product Details:
Place of Origin: Yixing, Jiangsu, China
Brand Name: BK
Certification: ISO9001 / ISO14001/CE
Model Number: BK6008
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: wooden case
Delivery Time: 15 days
Payment Terms: L/C, T/T
Supply Ability: 150 sets / month
Contact Now
Detailed Product Description
Material: Cast Iron Pressure: 10 Kpa - 80kpa
Capacity: 6.49-20.01m3/min Port Dia: 125 ( 5'' )
Speed: 850 - 1800 Rpm Weight: 371-625 Kg
Colour: Customizable
High Light:

three lobe roots type air blower

,

roots type air blower three lobe

,

three lobe positive displacement blower



Positive displacement cast iron Roots blower for ash blowing in power plant





1. Company brief



By advanced production & test equipment, technology and management method introduced from abroad, by



advanced management software, B-Tohin Machine ( Jaingsu ) Co.,Ltd. is committed to the production of high



efficient and energy-saving blowers. And it's our sincere wish that we supply high-quality products and good service.



Positive Displacement Cast Iron Roots Type Air Blower For Ash Blowing In Power Plant 0





2. Performance Parameters Sheet of BK6008



Model BK6008
Air capacity 6.49-20.01m3/min
Discharge differential pressure 10-80KPA
Rotary speed 850-1800rpm
Motor type 3-22KW
380/400/415/440V/220V, 3PHASES, 50/60HZ, frequencytype
Motor brand Standard: Siemens Beide or Wannan motor
Siemens and ABB motor for your option
Installation type Standard: horizontal type



*For different installation type and materials, please feel free to contact us.



Model Port Dia (MM) Speed Inlet airflow (m3/min)and shaft power(KW)
0.1kgf/cm2 0.2kgf/cm2 0.3kgf/cm2 0.4kgf/cm2 0.5kgf/cm2 0.6kgf/cm2 0.7kgf/cm2 0.8kgf/cm2
1000mmH2O 2000mmH2O 3000mmH2O 4000mmH2O 5000mmH2O 6000mmH2O 7000mmH2O 8000mmH2O
0.01Mpa 0.02Mpa 0.03Mpa 0.04Mpa 0.05Mpa 0.06Mpa 0.07Mpa 0.08Mpa
rpm m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW
BK6008 125 (5") 850 8.66 2.54 8.04 4.49 7.56 6.03 7.16 7.59 6.81 9.40 6.49 11.21
1000 10.45 2.99 9.83 5.28 9.35 7.10 8.95 8.93 8.60 11.06 8.28 13.19 7.98 14.81 7.72 16.85
1150 12.24 3.44 11.62 6.07 11.14 8.16 10.74 10.27 10.39 12.72 10.07 15.17 9.77 17.03 9.51 19.37
1250 13.44 3.74 12.82 6.60 12.34 8.87 11.93 11.16 11.59 13.82 11.26 16.49 10.97 18.51 10.70 21.06
1400 15.23 4.19 14.61 7.39 14.13 9.94 13.72 12.50 13.38 15.48 13.06 18.46 12.76 20.73 12.49 23.59
1500 16.42 4.49 15.80 7.92 15.33 10.65 14.92 13.40 14.57 16.59 14.25 19.78 13.95 22.22 13.69 25.27
1650 18.22 4.94 17.59 8.72 17.12 11.71 16.71 14.74 16.36 18.25 16.04 21.76 15.74 24.44 15.48 27.80
1800 20.01 5.39 19.39 9.51 18.91 12.78 18.50 16.08 18.16 19.91 17.83 23.74 17.54 26.66 17.27 30.32



Positive Displacement Cast Iron Roots Type Air Blower For Ash Blowing In Power Plant 1

Positive Displacement Cast Iron Roots Type Air Blower For Ash Blowing In Power Plant 2

3. Structure Drawings



Positive Displacement Cast Iron Roots Type Air Blower For Ash Blowing In Power Plant 3



1) Working smoothly as helical timing gears is adopted.

2) It is flexible mounting ways because of the same structure in inlet and outlet.

3) It adopts more reasonable bearing structure, which can increase the bearing operation life.

4) It is low noise, vibration and energy consumption.



Optional accessories and equipment



Blower enclosure

Positive Displacement Cast Iron Roots Type Air Blower For Ash Blowing In Power Plant 4

Positive Displacement Cast Iron Roots Type Air Blower For Ash Blowing In Power Plant 5
