Small Pneumatic Conveying 80kpa High Pressure Roots Blower

Small Pneumatic Conveying 80kpa High Pressure Roots Blower

  • Small Pneumatic Conveying 80kpa High Pressure Roots Blower
  • Small Pneumatic Conveying 80kpa High Pressure Roots Blower
Small Pneumatic Conveying 80kpa High Pressure Roots Blower
Product Details:
Place of Origin: China
Brand Name: BK
Certification: ISO9001/ISO14001/CE
Model Number: BK6005
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 5 to 20 working days, depends on order amount and specification
Payment Terms: L/C, T/T
Supply Ability: 100 SETS per month
Contact Now
Detailed Product Description
Air Capacity: 4.58-12.74m3/min Discharge Differential Pressure: 10-80KPA
Motor Power: 2.2-22KW Discharge Bore: DN80 (3”)
Cooling Type: Air Application:: Aeration, Backwashing, Pneumatic Conveying, Applied For Water Treatment, Cement, Pipe Clearing, Power Plant, Etc.
Bearing: NSK, SKF Foroption Color: Standard RAL6011, Or Customized
High Light:

80kpa high pressure roots blower

,

small high pressure roots blower

,

high pressure roots rotary lobe blower



Aeration Three Lobe Roots Blower, Rotary Blower, 10KPA - 80KPA, air blower





About BK



BK Roots Blower is a kind of product designed and manufactured according to the national standards.

This type blower is widely applied in sewage water treatment used as an areator.





Specifications:



Model

BK6005

Air capacity

3.54-11.74m3/min

Discharge differential pressure

10-80KPA

Rotary speed

850-1800rpm

Motor type

2.2KW-22KW

380/400/415/440V, 3PHASES, 50/60HZ

Motor brand

Standard: Siemens Beide or Wannan motor

Siemens and ABB motor for your option

Installation type

Standard: horizontal type.

Vertical type available for your option

N.W. of blower without motor

241 kg

Packing size Approx.

1.5*1.05*1.75m (length*width*height)





Features:

1. Helical type timing gears for smooth operation

2. Compact, flexibility in installation gives users more choices.

3. Integral structure of impeller and shaft to avoid shortcomings of the split structure

4. SKF oil seals made from fluoro rubber with good wear resistance and high-temperature resistance is installed.

5. Low vibration and small energy consumption.





Parameter sheet

Model Port Dia (MM) Speed Inlet airflow (m3/min)and shaft power(KW)
0.1kgf/cm2 0.2kgf/cm2 0.3kgf/cm2 0.4kgf/cm2 0.5kgf/cm2 0.6kgf/cm2 0.7kgf/cm2 0.8kgf/cm2
1000mmH2O 2000mmH2O 3000mmH2O 4000mmH2O 5000mmH2O 6000mmH2O 7000mmH2O 8000mmH2O
0.01Mpa 0.02Mpa 0.03Mpa 0.04Mpa 0.05Mpa 0.06Mpa 0.07Mpa 0.08Mpa
rpm m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW
BK6005 80 (3") 850 5.01 1.66 4.58 2.95 4.26 3.90 3.99 4.87 3.75 6.00 3.54 7.13
1000 6.07 1.95 5.65 3.47 5.33 4.59 5.05 5.73 4.82 7.06 4.60 8.39 4.40 9.45 4.22 10.73
1150 7.13 2.24 6.71 3.99 6.39 5.28 6.11 6.59 5.88 8.12 5.67 9.65 5.46 10.87 5.29 12.33
1250 7.84 2.44 7.42 4.34 7.10 5.74 6.82 7.16 6.59 8.82 6.38 10.49 6.17 11.82 5.99 13.41
1400 8.91 2.73 8.48 4.86 8.16 6.43 7.89 8.02 7.65 9.88 7.44 11.74 7.23 13.24 7.06 15.02
1500 9.61 2.92 9.19 5.21 8.87 6.89 8.59 8.60 8.36 10.59 8.15 12.58 7.94 14.18 7.76 16.09
1650 10.68 3.22 10.25 5.73 9.93 7.58 9.66 9.46 9.42 11.65 9.21 13.84 9.00 15.60 8.83 17.70
1800 11.74 3.51 11.31 6.25 11.00 8.27 10.72 10.32 10.49 12.71 10.27 15.10 10.07 17.02 9.89 19.31



Structure of blower main body


Small Pneumatic Conveying 80kpa High Pressure Roots Blower 0





No.

Part Name

Qty.



No.

Part Name

Qty.



No.

Part Name

Qty.

1

Footing

2



9

Left end cover

1



17

Oil tank

1

2

Hexagon bolt

4



10

Round pin

4



18

Gear

2

3

Antidust seal

1



11

Casing

1



19

Key

2

4

Drive impeller

1



12

Oil seal

4



20

Axial sleeve

2

5

Bearing

2



13

Right end cover

1



21

Bearing

2

6

Driven impeller

2



14

Bolt

16



22

Bearing plate

2

7

Dust cup

1



15

Breather

1



23

Adjustable pad

several

8

Grease nipple

2



16

Bolt

8



24

Magnetic nut

1





Assembling drawing of blower package



Small Pneumatic Conveying 80kpa High Pressure Roots Blower 1





Standard supply of scope



1. blower main body

2. pressure relieve valve

3. check valve

4. inlet muffler(with air filter)

5. discharge muffler

6. public base (with belt cover)

7. rubber flexible joint and shock pad

8. motor pulley

9. pressure gage

10. V-belt

11. bolts and nuts and other connection parts

12. electric motor
