Water Treatment Roots Air Blower 450 Rpm To 600 Rpm For Extensive Applications

Water Treatment Roots Air Blower 450 Rpm To 600 Rpm For Extensive Applications

    • Water Treatment Roots Air Blower 450 Rpm To 600 Rpm For Extensive Applications
    • Water Treatment Roots Air Blower 450 Rpm To 600 Rpm For Extensive Applications
  • Water Treatment Roots Air Blower 450 Rpm To 600 Rpm For Extensive Applications

    Product Details:

    Place of Origin: China
    Brand Name: B-Tohin
    Certification: ISO9001 / ISO14001
    Model Number: HC-201S

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: USD 320 - 350 / set
    Packaging Details: wooden case
    Delivery Time: 2 weeks
    Payment Terms: T/T, L/C
    Supply Ability: 1200 sets / month
    Contact Now
    Detailed Product Description
    Material: Casting Iron Motor Power: 0.37 KW
    Air Flow: 0.215-0.185 M3 / Min Excharge Dia: 3 / 4 '' ( 20 ) Mm
    Rpm: 600 Rpm Connect: Pulley
    High Light:

    rotary positive displacement blower

    ,

    Aeration blower



    Water Treatment Roots Air Blower 450 Rpm To 600 Rpm For Extensive Applications



    HC series rotary blowers adopt foreign advanced technology and processing technology. The main parts are



    processed by imported CNC lathes, bearing and oil seal all adopt high performance products, the key parts



    are imported products, the product performance has reached the domestic leading level.



    Water Treatment Roots Air Blower 450 Rpm To 600 Rpm For Extensive Applications 0



    (1) Low noise, energy consumption, smooth operation and easy installation.



    (2) Anti-load change, stable air volume, with air-chamber, stable air.



    (3) Excellent material, clever structure, excellent performance.



    2 Working principle



    Water Treatment Roots Air Blower 450 Rpm To 600 Rpm For Extensive Applications 1



    The blower relies on eccentric rotor eccentric operation in the cylinder, and the volume changes between



    the blades in the rotor slot can be inhaled, compressed and exhaled. In operation, the pressure difference



    of the blower is used to automatically send lubricant to the dripping nozzle to reduce the friction and noise



    in the cylinder, while reducing the backflow of the gas in the cylinder.



    Main components



    Water Treatment Roots Air Blower 450 Rpm To 600 Rpm For Extensive Applications 2 Water Treatment Roots Air Blower 450 Rpm To 600 Rpm For Extensive Applications 3 Water Treatment Roots Air Blower 450 Rpm To 600 Rpm For Extensive Applications 4



    Cylinder: The inner wall is honed, and the surface quality is higher. The end face opens the seal groove,



    and the sealing ring is used to ensure the air tightness.



    Water Treatment Roots Air Blower 450 Rpm To 600 Rpm For Extensive Applications 5 Water Treatment Roots Air Blower 450 Rpm To 600 Rpm For Extensive Applications 6 Water Treatment Roots Air Blower 450 Rpm To 600 Rpm For Extensive Applications 7



    Rotor: It is machined by CNC lathe with higher precision.





    4 Model parameter



    model airflow(m³/min) pressure(kgf/cm²)
    HC-20S 0.14-0.16 0.1-0.5
    HC-201S 0.18-0.21 0.1-0.5
    HC-25S 0.23-0.28 0.1-0.5
    HC-251S 0.28-0.31 0.1-0.5
    HC-30S 0.31-0.35 0.1-0.5
    HC-301S 0.38-0.42 0.1-0.5
    HC-40S 0.59-0.66 0.1-0.5
    HC-401S 0.67-0.8 0.1-0.5
    HC-50S 1.02-1.14 0.1-0.5
    HC-501S 1.32-1.44 0.1-0.5
    HC-60S 1.71-1.9 0.1-0.5
    HC-601S 2.18-2.41 0.1-0.5
    HC-80S 2.5-2.82 0.1-0.5
    HC-801S 3.25-3.53 0.1-0.5
    HC-100S 4.11-4.32 0.1-0.5
    HC-1001S 5.11-5.41 0.1-0.5





    5 Noise curve



    Water Treatment Roots Air Blower 450 Rpm To 600 Rpm For Extensive Applications 8



    6 Installation diagam



    Water Treatment Roots Air Blower 450 Rpm To 600 Rpm For Extensive Applications 9



    7 Chief application



    (1) Water treatment of blast aeration.



    (2) Sewage stirring aeration in hospital and laboratory.



    (3) Vacuum delivery in the printing industry.



    (4) The stirring aeration of electroplating bath and industrial wastewater.



    (5) Spray of burner, glass industry and others.
