    Product Details:

    Place of Origin: China
    Brand Name: BK
    Certification: ISO9001/ISO14001
    Model Number: 50YU2.75

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiation
    Packaging Details: Export standard wooden case
    Delivery Time: 10-20 working days, depends on order amount and specification
    Payment Terms: L/C, T/T
    Supply Ability: 100 SETS per month
    Contact Now
    Detailed Product Description
    Model: 50YU2.75 Motor Power: 0.75KW
    Main Materials: Stainless Steel And Resin Bore: 50mm
    Flow: 6-12m Head: 10.8-21.6m3/h
    Application:: Drainage, Sewage, Wastewater, Domestic Water
    High Light:

    submersible wastewater pumps

    ,

    commercial sewage pumps





    Irrigation Submersible Sewage Pump 50YU2.75, DN50 bore size, wastewater pump






    About YU pump


    YU series pump is small type pump used for drainage, agricultural irrigation and water treatment. It is a multi-purpose pump with a vortex impeller, featured of small size and light weight. It is durable in use.

    .



    Working Conditions



    • The medium temperature should not be over 40 , the density 1200Kg/m3 , and the PH value within 5-9



    • During running, the pump must not be lower than the lowest liquid level, See the specific requirements of the drawing of installation dimensions.



    • The maximum diameter of the solid grain going through the pump has not to be larger than 50% of that of the pump outlet.




    Specifications



    Model No.

    50YU2.75

    Motor Power

    0.75KW

    Main Materials

    Stainless steel and resin

    Bore

    50mm

    Rated Flow

    10.8m3/h

    Maximum Flow

    21.6m3/h

    Rated Head

    6m

    Maximum Head

    12m

    Solid passable

    Solid diameter ≦ 14

    N.W. of pump

    8.5kg

    Dimension

    0.25*0.17*0.33m (length*width*height)

    Packing size Approx.

    0.27*0.19*0.36m (length*width*height)








    Features

    • Vortex type impeller is made from special resin with optimized design.



    • Double silicon carbide mechanical seal separate the motor from the pump seal to provide the motor with a dual protection.



    • Three-phase asynchronous motor,IP54,F,max. working temperature is 155 degrees Celsius. Motor winding with embedded thermal protection device enabling the motor overheating protection.



    • Heavy-duty water-resistant rubber-sheath soft cable is used and special cable sheath and cable seals are also adopted.



    • Brand-name deep groove ball bearing with sufficient load capacity selected.



    • Oil can lubricate and cool the mechanical seal and the air of a certain amount left inside the chamber can lower the pressure accumulatively raised.

    • Shaft made of SUS410 stainless steel, shaft end with sealing device for preventing the shaft being corroded.






    Performance curve



    Submersible Irrigation Pump 50YU2.75, DN50 bore size , submersible wastewater pumps 0








    Structure and materials of pump



    Submersible Irrigation Pump 50YU2.75, DN50 bore size , submersible wastewater pumps 1
