Stainless Submersible Mixer QJB4.0 , anti-corrosive multiple flow stirrer

Stainless Submersible Mixer QJB4.0 , anti-corrosive multiple flow stirrer

Stainless Submersible Mixer QJB4.0 , anti-corrosive multiple flow stirrer

Product Details:

Place of Origin: China
Brand Name: BK
Certification: ISO9001/ISO14001
Model Number: QJB4.0/12-615/3-480S

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 5-20 working days, depends on order amount and specification
Payment Terms: L/C, T/T
Supply Ability: 200 SETS per month
Contact Now
Detailed Product Description
Model: QJB4.0/12-615/3-480S Motor Power: 4.0KW
Main Materials: Stainless Steel Rotary Speed: 480rpm
Diameter Of Blade: 615mm Axial Thrust (N)): 1100
Application:: Water Treatment, Applied For Densification Process, Sludge Dewatering Process, Heat Transfer, And Cesspit Clean





QJB4.0/12-615/3-480S Submersible Mixer, submerged stirrer multiple flowing modes






About QJB mixer


QJB series submersible mixer is suitable for both aeration and anaerobic tanks in the industrial and city’s sewage treatment to provide the power for the cycle of the water in the tank and establish the water flow in the phases of nitration, de-nitrification and phosphor removal.

.



Working Conditions



The submersible mixer can be continuous operation in the conditions as below:

  • The maximum medium temperature be less than 40℃
  • Medium PH value be in 5~9
  • Medium density be less than 1150kg/m3
  • Continuous operation, the depth be less than 20m




Specifications



Model No.

QJB4.0/12-615/3-480S

Model meaning:

QJB—submersible mixer

4.0—rated motor power of mixer

12—poles of motor

615—diameter of impeller

3—quantity of impeller

480—rated speed of mixer

S—stainless steel

Motor Power

4.0KW

380/400/415/440V, 3PHASES, 50/60HZ, 6 Poles

Rated Current

14A

Main Materials

Stainless steel

Rotary speed

480r/min

Diameter of Blade

615

Axial thrust

1100

Installation system

Equipped according to tank depth

Including leader, leader base, lifting head, support frame, limit frame, etc.

N.W. of mixer without installing system

184kg

Packing size without installing system Approx.

615*605*935m (length*width*height)

Flow rate drawing Stainless Submersible Mixer QJB4.0 , anti-corrosive multiple flow stirrer






Features



  • Compact structure, small volume, light weight, easy maintenance and installation, long service life.



  • Optimal impeller for high efficiency, and sweep back type blade to prevent clogging, also can be self-cleaning.



  • When use together with aerating system, it can reduce power consumption, increase oxygen content, and prevent sedimentation.



  • F class insulation for motor wiring, IP 68 class protection level, maintenance-free type bearing, be with oil leakage detection and overheat protection, which can assure stable operation for the motor.



  • The mixer will be equipped with two way mechanical seal.



  • The mixer can be used either with flow guide sleeve or not. The faring can enhance the efficiency and control the flow spraying.




Advantage



Compared with the conventional long axle stirrer, model QJB submersible stirrer features the advantage able to produce different flow directions, and with the the different positions, it can get multiple flowing modes of different effects so as to create a better flowing mode in the pool to remove the dead corner of stirring.






Structure of Mixer



Stainless Submersible Mixer QJB4.0 , anti-corrosive multiple flow stirrer




Installation diagram



Stainless Submersible Mixer QJB4.0 , anti-corrosive multiple flow stirrer
