Cast Iron Roots Blower Vacuum Pump , vacuum roots blower for chemical industry

Cast Iron Roots Blower Vacuum Pump , vacuum roots blower for chemical industry

  • Cast Iron Roots Blower Vacuum Pump , vacuum roots blower for chemical industry
Cast Iron Roots Blower Vacuum Pump , vacuum roots blower for chemical industry
Product Details:
Place of Origin: China
Brand Name: BK
Certification: ISO9001/ISO14001
Model Number: BV7011
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export standard wooden caseAbout BKW BKW series roots blower inherits the design of BK series. It adopts water cooling in bearing cover, which can lower the temperature of bearing so as to prolong the bearing’s service life and enable higher pressure appli
Delivery Time: 5 to 20 working days, depends on order amount and specification
Payment Terms: L/C, T/T
Supply Ability: 80 SETS per month
Contact Now
Detailed Product Description
Type: Vacuum Sauction, Roots Type Air Capacity: 11.41-31.51m3/min
Discharge Differential Pressure: -10KPA - -40KPA Motor Power: 5.5KW-30KW
Discharge Bore: DN150(6”) Cooling Type: Air
Driven Type: Motor Driven, Connected By Belt And Pulley
High Light:

roots type vacuum pump

,

air blower pump


Cast Iron Roots Blower Vacuum Pump,  vacuum roots blower, convey vacuum air


About BK vacuum pump

Based on our BK series positive Roots blower, we developed BK vacuum pump for vacuum application.

Its maximum vacuum pressure can reach -40KPA. Widely applied in vacuum application in food conveying, metallurgy, chemical industry,electronic coating and other industries,  it is the reliable and perfect product due to its good vacuum performance and stable vacuum air capacity input.

Specifications

Model

BV7011

Inlet dimensionDN150
Outlet dimensionDN150

Air capacity

11.41-31.51m3/min

Discharge differential pressure

-10   ~   -40KPA

Rotary speed

700-1500rpm

Motor type

5.5-30KW
380/400/415/440V, 3PHASES, 50/60HZ

Motor brand

Standard: Siemens Beide or Wannan motor
Siemens and ABB motor for your option

Motor efficiency gradeIE3
Moror insulation classF, temperature rising B
Motor protection classIP55

Installation type

Standard: horizontal type.
Vertical type available for your option

N.W. of blower without motor

477kg

Packing size Approx.

1.8*1.2*2.0m (length*width*height)


Parameter sheet


ModelPort Dia
(MM)
SpeedInlet capacity (m3/min)and shaft power (KW)
-0.1kgf/cm2-0.2kgf/cm2-0.3kgf/cm2-0.4kgf/cm2
-1000mmH2O-2000mmH2O-3000mmH2O-4000mmH2O
-0.01Mpa-0.02Mpa-0.03Mpa-0.04Mpa
rpmm3/minKWm3/minKWm3/minKWm3/minKW
BV7011150(6")70013.57 3.77 12.67 6.60 11.97 8.98 11.41 11.87
85016.93 4.57 16.03 8.01 15.34 10.90 14.78 14.41
100020.29 5.38 19.40 9.42 18.70 12.83 18.14 16.95
115023.66 6.19 22.76 10.84 22.07 14.75 21.50 19.50
125025.90 6.73 25.00 11.78 24.31 16.03 23.75 21.19
140029.26 7.53 28.37 13.19 27.67 17.96 27.11 23.73
150031.51 8.07 30.61 14.13 29.91 19.24 29.35 25.43



Assembling drawing of blower package

Cast Iron Roots Blower Vacuum Pump , vacuum roots blower for chemical industry 0
 * Vertical installation also available

Standard supply of scope

1. blower main body
2. vacuum safety valve
3. inlet silencer
4. outlet silencer
5. public base (with belt cover)
6. rubber flexible joint and shock pad
7. blower pulley
8. pressure gauge
9. belt
10. bolts and nuts and other connection parts
11. motor
