Low Noise Air Three Lobe Roots Blower with Pressure 10-60KPA Roots Aerator

Low Noise Air Three Lobe Roots Blower with Pressure 10-60KPA Roots Aerator

  • Low Noise Air Three Lobe Roots Blower with Pressure 10-60KPA Roots Aerator
  • Low Noise Air Three Lobe Roots Blower with Pressure 10-60KPA Roots Aerator
  • Low Noise Air Three Lobe Roots Blower with Pressure 10-60KPA Roots Aerator
  • Low Noise Air Three Lobe Roots Blower with Pressure 10-60KPA Roots Aerator
  • Low Noise Air Three Lobe Roots Blower with Pressure 10-60KPA Roots Aerator
  • Low Noise Air Three Lobe Roots Blower with Pressure 10-60KPA Roots Aerator
Low Noise Air Three Lobe Roots Blower with Pressure 10-60KPA Roots Aerator
Product Details:
Place of Origin: China
Brand Name: BK
Certification: ISO9001/ISO14001/CE
Model Number: BK8016
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 5 to 20 working days, depends on order amount and specification
Payment Terms: L/C, T/T
Supply Ability: 100 SETS per month
Contact Now
Detailed Product Description
Air Capacity: 15.37-48.99m3/min Maximum Discharge Pressure: 60KPA
Motor Power: 11-90KW Discharge Bore: DN200 (8”)
Application:: Aeration, Backwashing, Pneumatic Conveying, Applied For Water Treatment, Cement Factory, Printing Plant, Etc. Main Materials: Cast Iron
Origin Of Technology: USA Bearing Brand: NSK, SKF For Customer's Option
High Light:

3 Lobe Roots Blower

,

pneumatic conveying blower

Positive Three Lobe Roots Blower, pressure 10-50KPA, rotary speed 700-1500rpm


Roots blower is widely used in electricity,petroleum,steel industry,smelling,food,oxygen making,spinning,

vacuum packing,paper making,aquaculture,sewage treatment,pneumatic conveying,etc.





Specifications:



Model

BK8016

Air capacity

15.37-48.99m3/min

Discharge differential pressure

10-60KPA

Rotary speed

700-1500rpm

Motor type

11KW-90KW

380/400/415/440V, 3PHASES, 50/60HZ, frequency motor also available

Motor brand

Standard: Siemens Beide or Wannan motor

Siemens and ABB motor for your option

Installation type

Standard: horizontal type

Vertical type available for your option

Color Customized, standard of RAL6011

N.W. of blower without motor

800 kg

Packing size Approx.

2.1*1.5*2.35 (length*width*height)





Features:

1. Helical type timing gears for smooth operation

2. Compact, flexibility in installation gives users more choices.

3. Adopt integral structure of impeller, more stable in operation.

4. Adopt imported oil seals made from fluoric rubber, which is of good wear resistance and high-temperature resistance.

5. Small vibration and economical energy consumption.





Parameter sheet

Model Port Dia
(MM)
Speed Inlet capacity (m3/min)and shaft power (KW)
0.1kgf/cm2 0.2kgf/cm2 0.3kgf/cm2  0.4kgf/cm2
1000mmH2O 2000mmH2O 3000mmH2O 4000mmH2O
0.01Mpa 0.02Mpa 0.03Mpa 0.04Mpa
rpm m3/min KW m3/min KW m3/min KW m3/min KW
BK8016 200(8") 700 20.85 8.26 19.27 12.32 18.08 16.13 17.06 18.28
850 26.13 10.03 24.55 14.96 23.35 19.58 22.33 22.19
1000 31.40 11.81 29.82 17.60 28.63 23.04 27.61 26.11
1150 36.68 13.58 35.10 20.24 33.90 26.50 32.88 30.03
1250 40.20 14.76 38.61 22.00 37.42 28.80 36.40 32.64
1400 45.47 16.53 43.89 24.63 42.69 32.26 41.67 36.55
1500 48.99 17.71 47.41 26.39 46.21 34.56 45.19 39.16



Model Port Dia
(MM)
Speed Inlet capacity (m3/min)and shaft power (KW)
0.5kgf/cm2  0.6kgf/cm2 0.7kgf/cm2 0.8kgf/cm2
5000mmH2O 6000mmH2O 7000mmH2O 8000mmH2O
0.05Mpa 0.06Mpa 0.07Mpa 0.08Mpa
rpm m3/min KW m3/min KW m3/min KW m3/min KW
BK8016 200(8") 700 16.18 22.44 15.37 26.60
850 21.45 27.25 20.64 32.31
1000 26.73 32.06 25.92 38.01 25.18 43.96 24.51 49.90
1150 32.00 36.87 31.19 43.71 30.45 50.55 29.79 57.39
1250 35.52 40.07 34.71 47.51 33.97 54.94 33.30 62.38
1400 40.79 44.88 39.98 53.21 39.25 61.54 38.58 69.87
1500 44.31 48.09 43.50 57.01 42.76 65.93 42.09 74.86





Structure of blower main body


Low Noise Air Three Lobe Roots Blower with Pressure 10-60KPA Roots Aerator 0



No.

Part Name

Qty.



No.

Part Name

Qty.



No.

Part Name

Qty.

1

Footing

2



9

Left end cover

1



17

Oil tank

1

2

Hexagon bolt

4



10

Round pin

4



18

Gear

2

3

Antidust seal

1



11

Housing

1



19

Key

2

4

Drive impeller

1



12

Oil seal

4



20

Axial sleeve

2

5

Drive end bearing

2



13

Right end cover

1



21

Gear end bearing

2

6

Driven impeller

2



14

Bolt

16



22

Bearing plate

2

7

Dust cover

1



15

Breather

1



23

Adjustable pad

several

8

Grease nipple

2



16

Mounting bolt

8



24

Magnetic nut

1





Assembling drawing of blower package



Low Noise Air Three Lobe Roots Blower with Pressure 10-60KPA Roots Aerator 1





Standard supply of scope



1. bare shaft blower

2. relieve valve

3. slime type wafer check valve

4. inlet silencer(with air filter)

5. discharge silencer

6. Blower and motor base (with belt cover)

7. rubber flexible joint and shock absorber

8. motor pulley

9. pressure meter

10. V-belt

11. bolts and nuts and other connection parts

12. electric motor
