Positive Displacement Three Lobe Roots Blower For Conveying In Cement Plant

Positive Displacement Three Lobe Roots Blower For Conveying In Cement Plant

    • Positive Displacement Three Lobe Roots Blower For Conveying In Cement Plant
    • Positive Displacement Three Lobe Roots Blower For Conveying In Cement Plant
  • Positive Displacement Three Lobe Roots Blower For Conveying In Cement Plant

    Product Details:

    Place of Origin: Yixing, Jiangsu, China
    Brand Name: BK
    Certification: ISO9001 / ISO14001/CE
    Model Number: BK6008

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: USD 1550-2400 per set
    Packaging Details: wooden case
    Delivery Time: 15 days
    Payment Terms: L/C, T/T
    Supply Ability: 150 sets / month
    Contact Now
    Detailed Product Description
    Material: Cast Iron Pressure: 10 Kpa - 80kpa
    Colour: Customizable Port Dia: 125 ( 5'' )
    Speed: 850 - 1800rpm Weight: 371-625 Kg
    High Light:

    1800rpm air root blower

    ,

    80kpa air root blower

    ,

    three lobe roots rotary blower



    Positive displacement cast iron Roots blower for ash blowing in power plant





    1. Company brief



    By advanced production & test equipment, technology and management method introduced from abroad, by



    advanced management software, B-Tohin Machine ( Jaingsu ) Co.,Ltd. is committed to the production of high



    efficient and energy-saving blowers. And it's our sincere wish that we supply high-quality products and good service.



    Positive Displacement Three Lobe Roots Blower For Conveying In Cement Plant 0





    2. Performance Parameters Sheet of BK6008



    Model BK6008
    Air capacity 7.96-20.63m3/min
    Discharge differential pressure 10-80KPA
    Rotary speed 850-1800rpm
    Motor type 3-22KW
    380/400/415/440V/220V, 3PHASES, 50/60HZ, frequencytype
    Motor brand Standard: Siemens Beide or Wannan motor
    Siemens and ABB motor for your option
    Installation type Standard: horizontal type



    *For different installation type and materials, please feel free to contact us.



    Manufacturing standards and specifications



    The products provided by the supplier are manufactured according to the following standards:

    1.1 JISB8341-1995 "Displacement compressor test and inspection method"

    1.2 JB/T8941.1-1999 "Conditions for Roots Blower for General Application"

    1.3 JB/T8941.2-1999 "Performance Test Method for Roots Blower for General Application "

             1.4 GB/T 13306-91 GB / T 13306-91 "Nameplate"




    Parameter Table
    Model Port Dia (MM) Speed Inlet airflow (m3/min)and shaft power(KW)
    0.1kgf/cm2 0.2kgf/cm2 0.3kgf/cm2 0.4kgf/cm2 0.5kgf/cm2 0.6kgf/cm2 0.7kgf/cm2 0.8kgf/cm2
    1000mmH2O 2000mmH2O 3000mmH2O 4000mmH2O 5000mmH2O 6000mmH2O 7000mmH2O 8000mmH2O
    0.01Mpa 0.02Mpa 0.03Mpa 0.04Mpa 0.05Mpa 0.06Mpa 0.07Mpa 0.08Mpa
    rpm m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW
    BK4005 40
    (1.5")
    1500 1.01 0.82 0.81 0.96 0.66 1.11 0.53 1.25 0.42 1.40
    1650 1.16 0.90 0.96 1.06 0.81 1.22 0.68 1.38 0.57 1.54 0.53 1.80
    1800 1.31 0.98 1.12 1.16 0.96 1.33 0.85 1.50 0.74 1.68 0.68 1.90
    1900 1.42 1.04 1.20 1.22 1.11 1.40 1.05 1.59 0.93 1.77 0.73 1.95 0.73 2.14
    2150 1.65 1.17 1.45 1.38 1.30 1.59 1.17 1.80 1.06 2.00 0.96 2.21 0.87 2.42 0.78 2.63
    2300 1.80 1.26 1.60 1.48 1.45 1.70 1.32 1.92 1.21 2.14 1.11 2.36 1.02 2.59 0.93 2.81





    Positive Displacement Three Lobe Roots Blower For Conveying In Cement Plant 1



    3. Dimension drawing

    11-15KW

    Positive Displacement Three Lobe Roots Blower For Conveying In Cement Plant 2Positive Displacement Three Lobe Roots Blower For Conveying In Cement Plant 3





    18.5-22KW

    Positive Displacement Three Lobe Roots Blower For Conveying In Cement Plant 4



    30KW

    Positive Displacement Three Lobe Roots Blower For Conveying In Cement Plant 5



    4. Pipeline drawing

    Positive Displacement Three Lobe Roots Blower For Conveying In Cement Plant 6





    5. Advantages



    1) The material of transmission gear is 40Cr, which is processed by high-frequency quenching, manufactured by grinding gears, with 5 grade accuracy, and its service life reaches 50,000 hours. The gear transmission part and outer cover are made of cast iron and have sufficient rigidity to maintain the position of the shaft under maximum load. The parts of the gear cover are precisely processed for installation with the bearings.

    2) It is flexible mounting ways because of the same structure in inlet and outlet.

    3) It adopts more reasonable bearing structure, which can increase the bearing operation life.

    4) It is low noise, vibration and energy consumption.





    6. Accessories



    Relieve valve

    It is a safety device on the system. When the system works abnormally and the resistance is higher than the rated value, the pressure relief valve opens to discharge the air from the pressure relief valve to prevent the blower and motor from being overload.

    Positive Displacement Three Lobe Roots Blower For Conveying In Cement Plant 7



    Check valve

    It is used to prevent back-flow of high-pressure air in the system during shutdown. The back-flow can cause blower reversion and then cause blower malfunctions. The valve body is made of cast iron.

    Positive Displacement Three Lobe Roots Blower For Conveying In Cement Plant 8
