100KPA 19.59-42.18 m³/min Rotary Positive Displacement Roots Style Blower

100KPA 19.59-42.18 m³/min Rotary Positive Displacement Roots Style Blower

100KPA 19.59-42.18 m³/min Rotary Positive Displacement Roots Style Blower

100KPA 19.59-42.18 m³/min Rotary Positive Displacement Roots Style Blower

100KPA 19.59-42.18 m³/min Rotary Positive Displacement Roots Style Blower

Product Details:

Place of Origin:	China
Brand Name:	BK
Certification:	ISO9001/ISO14001/CE
Model Number:	BKW8016S

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	Export standard wooden case
Delivery Time:	5 to 20 working days, depends on order amount and specification
Payment Terms:	L/C, T/T
Supply Ability:	100 SETS per month

Contact Now

Detailed Product Description

Name:	Roots Rotary Lobe Blower	Type:	Positive Displacement Roots Type, Three Lobes
Air Capacity:	19.59-42.18m³/min	Discharge Differential Pressure:	60-100KPA
Motor Power:	30-90W	Discharge Bore:	DN150 (6”)
Driven Type:	Motor Driven, Connected By Belt And Pulley	Installation Type:	Horizontal, Vertical Available Also
Highlight:	100KPA roots blower , 2400m3 / hour roots blower , three lobes roots style blower

100KPA Roots Rotary Lobe Blower, capacity 2400m3/hour air blower

Roots blower is a kind of volumetric blower whose air capacity and revolution have formed a proportion. Each rotation of the three-lobe type blower needs three times of air suction & discharge of two-lobes. Compared to two-lobe type blower, three lobe roots blower have the characteristics of low air pulsation changes than two-lobe roots blowers.

Specifications

Model	BKW8016S
Air capacity	19.59-42.18m³/min
Discharge differential pressure	60-100KPA
Rotary speed	850-1500rpm
Cooling water volume	10 L/min
Motor type	30-90KW 380/400/415/440V, 3PHASES, 50/60HZ
Motor brand	Standard: Siemens Beide or Wannan motor Siemens and ABB motor for your option
Installation type	Standard: horizontal type. Vertical type available for your option
N.W. of blower without motor	730kg
Packing size Approx.	2.11.42.26m (LWH)

Features

1. Delivers completely oil-free air.
2. The specially designed rotor runs smoothly
3. Small change in capacity against change in pressure.
4. High efficiency due to special profile.
5. Compact structure is easy to fix and safe to use

Applications

1. petrochemical industry

2. construction materials

3. electric power, metallurgy

4. chemical fertilizer

5. paper making

6. aquaculture and wastewater treatment,

7. environmental protection industry

Parameter sheet

Model	Speed	Inlet capacity (m3/min)and shaft power (KW)										Cool-
		0.6kgf/cm2		0.7kgf/cm2		0.8kgf/cm2		0.9kgf/cm2		1.0kgf/cm2		ing
		6000mmH2O		7000mmH2O		8000mmH2O		9000mmH2O		10000mmH2O		Water
		0.06Mpa		0.07Mpa		0.08Mpa		0.09Mpa		0.1Mpa
	rpm	m3/min	KW	m3/min	KW	m3/min	KW	m3/min	KW	m3/min	KW	L/min
BKW8016S	850	20.27	30.33	19.59	33.68							10
BKW8016S	1000	25.32	35.68	24.65	39.63	24.02	43.57	23.44	47.52	22.88	51.47
Port	1150	30.38	41.03	29.71	45.57	29.08	50.11	28.49	54.65	27.94	59.19
Dia:	1250	33.75	44.60	33.08	49.53	32.45	54.47	31.87	59.40	31.31	64.33
DN150	1400	38.81	49.95	38.14	55.48	37.51	61.00	36.92	66.53	36.37	72.05
(6")	1500	42.18	53.52	41.51	59.44	40.88	65.36	40.29	71.28	39.74	77.20

Structure of blower main body

100KPA 19.59-42.18 m³/min Rotary Positive Displacement Roots Style Blower 0

Flow direction of cooling water

100KPA 19.59-42.18 m³/min Rotary Positive Displacement Roots Style Blower 1

Assembling drawing of blower package

100KPA 19.59-42.18 m³/min Rotary Positive Displacement Roots Style Blower 2

Standard supply of scope

1. shaft blower

2. inlet silencer (with air filter)

3. outlet silencer

4. relieve valve

5. check valve

6. flexible joint

7. pressure gage

8. blower pulley and motor pulley

9. V-belt

10. belt cover
11. public base

12. motor

Optional auto-start valve

100KPA 19.59-42.18 m³/min Rotary Positive Displacement Roots Style Blower 3
