Pressure 10KPA Positive 700 Rpm 1500rpm Tri Lobe Blower

Pressure 10KPA Positive 700 Rpm 1500rpm Tri Lobe Blower

Pressure 10KPA Positive 700 Rpm 1500rpm Tri Lobe Blower
Pressure 10KPA Positive 700 Rpm 1500rpm Tri Lobe Blower
Pressure 10KPA Positive 700 Rpm 1500rpm Tri Lobe Blower
Product Details:
Place of Origin: China
Brand Name: BK
Certification: ISO9001/ISO14001/CE
Model Number: BK7018
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 5 to 20 working days, depends on order amount and specification
Payment Terms: L/C, T/T
Supply Ability: 100 SETS per month
Contact Now
Detailed Product Description
Name: Three Lobe Roots Blower Air Capacity: 18.98-50.47m3/min
Discharge Differential Pressure: 10-50KPA Motor Power: 11-55KW
Discharge Bore: DN200 (8”) Application:: Aeration, Backwashing, Pneumatic Conveying, Applied For Water Treatment, Cement Factory, Printing Plant, Etc.
Main Materials: Cast Iron Origin Of Technology: USA
Connected By: Belt And Pulley Blower RPM: 700-1500
Voltage&Frequency: 380V/400V/415V/440V&50Hz60Hz Package: Export Wooden Case & Moisture-proof Plastic Film
High Light:

3 Lobe Roots Blower

,

10kpa tri lobe blower

,

1500rpm tri lobe blower

Positive Three Lobe Roots Blower, pressure 10-50KPA, rotary speed 700-1500rpm



Used in petrochemical industry, building materials, electric power, metallurgy, chemical fertilizer, mines, ports, textile, food, paper making, aquaculture and wastewater treatment and other fields, mostly used to transport the air. For gas and hydrogen gas, acetylene, carbon dioxide, flammable, explosive and corrosive gas application, please refer to our another model bio gas blower YU-EG series.



Specifications:



Model

BK7018

Air capacity

18.98-50.47m3/min

Discharge differential pressure

10-50KPA

Rotary speed

700-1500rpm

Motor type

11KW-55KW

380/400/415/440V, 3PHASES, 50/60HZ, frequency motor also available

Motor brand

Standard: Siemens Beide or Wannan motor

Siemens and ABB motor for your option

Installation type

Standard: horizontal type

Vertical type available for your option

Color Customized, standard of RAL6011

N.W. of blower without motor

564 kg

Packing size Approx.

1.8*1.3*2.2 (length*width*height)





Features:

1. Helical type timing gears for smooth operation

2. Compact, flexibility in installation gives users more choices.

3. Integral structure of impeller, more stable in air flow transmission

4. Adopt imported oil seals made from fluoro rubber, which is of fine wear resistance and high-temperature resistance.

5. Small vibration and economical energy consumption.



Parameter sheet

Model Port Dia (MM) Speed Inlet airflow (m3/min)and shaft power(KW)
0.1kgf/cm2 0.2kgf/cm2 0.3kgf/cm2 0.4kgf/cm2 0.5kgf/cm2
1000mmH2O 2000mmH2O 3000mmH2O 4000mmH2O 5000mmH2O
0.01Mpa 0.02Mpa 0.03Mpa 0.04Mpa 0.05Mpa
rpm m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW
BK7018 200 (8") 700 21.97 6.55 20.73 10.70 19.77 14.52 18.98 19.46
850 27.32 7.96 26.07 13.00 25.11 17.63 24.32 23.62 23.61 26.82
1000 32.66 9.36 31.41 15.29 30.45 20.74 29.67 27.79 28.95 31.55
1150 38.00 10.76 36.75 17.58 35.79 23.85 35.01 31.96 34.30 36.28
1250 41.56 11.70 40.32 19.11 39.35 25.92 38.57 34.74 37.86 39.44
1400 46.90 13.11 45.66 21.40 44.70 29.03 43.91 38.91 43.20 44.17
1500 50.47 14.04 49.22 22.93 48.26 31.11 47.47 41.69 46.76 47.33







Structure of blower main body


Pressure 10KPA Positive 700 Rpm 1500rpm Tri Lobe Blower 0





No.

Part Name

Qty.



No.

Part Name

Qty.



No.

Part Name

Qty.

1

Footing

2



9

Left end cover

1



17

Oil tank

1

2

Hexagon bolt

4



10

Round pin

4



18

Gear

2

3

Antidust seal

1



11

Casing

1



19

Key

2

4

Drive impeller

1



12

Oil seal

4



20

Axial sleeve

2

5

Drive end bearing

2



13

Right end cover

1



21

Gear end bearing

2

6

Driven impeller

2



14

Bolt

16



22

Bearing plate

2

7

Dust cover

1



15

Breather

1



23

Adjustable pad

several

8

Grease nipple

2



16

Mounting bolt

8



24

Magnetic nut

1





Assembling drawing of blower package



Pressure 10KPA Positive 700 Rpm 1500rpm Tri Lobe Blower 1





Standard supply of scope



1. bare shaft blower

2. relieve valve

3. wafer check valve (slim type)

4. inlet silencer(with air filter)

5. discharge silencer

6. Blower and motor base (with belt cover)

7. rubber flexible joint and shock absorber

8. motor pulley

9. pressure meter

10. V-belt

11. bolts and nuts and other connection parts

12. electric motor



Optional  spares



Belt, filter sponge, seals, bearings.
