0.8 Bar 132kw 10" 850-1500 Rpm 71.52-116.5m3/Min Tri Lobe Roots Blower

0.8 Bar 132kw 10" 850-1500 Rpm 71.52-116.5m3/Min Tri Lobe Roots Blower

0.8 Bar 132kw 10" 850-1500 Rpm 71.52-116.5m3/Min Tri Lobe Roots Blower
0.8 Bar 132kw 10
0.8 Bar 132kw 10" 850-1500 Rpm 71.52-116.5m3/Min Tri Lobe Roots Blower
Product Details:
Place of Origin: China
Brand Name: BK
Certification: ISO9001/ISO14001/CE
Model Number: BK9030S
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 30 working days after receiving advance payment
Payment Terms: L/C, T/T
Supply Ability: 50 Sets /Month
Contact Now
Detailed Product Description
Product Name: Three Lobe Roots Blower Type: Positive Displacement, Roots Type, Air Conveying
Air Capacity: 71.52-1116.5m3/min Discharge Differential Pressure: 0.1-0.8kgf/cm²
Motor Power: 132KW Discharge Bore: DN250 (10”)
Cooling Type: Air Application: Aeration, Backwashing, Pneumatic Conveying, Applied For Water Treatment, Cement, Pipe Clearing, Power Plant, Etc.
Main Materials: Cast Iron Speed: 850-1500 Rpm
Voltage: 380V/400V/415V/440V/Customed Frequency: 50HZ/60HZ
Highlight:

0.8 bar tri lobe roots blower

,

132kw tri lobe roots blower

,

three lobe root blower



0.8bar, 132KW, 10", 850-1500rpm, 71.52-116.5m3/min three Lobe Roots aeration air Blower



  Roots Blower is a cubage blower, and it discharges a fixed amount of air in proportion to its rotation speed.Every rotation,there is two lobes to finish three times absorbing and discharging air.Compared with two lobes blower,it is of less air pulses,smaller load change,higher strength,lower noise and vibration.





Specifications:



Model

BK9030S

Air capacity

71.52-116.5m3/min

Discharge differential pressure

80KPA

Rotary speed

850-1500rpm

Motor type

37-90/110-220KW

380/400/415/440V, 3PHASES, 50/60HZ, frequency motor also available

Motor brand

Standard: Siemens Beide or Wannan motor

Siemens and ABB motor for your option

Installation type

Standard: horizontal type.

Vertical type available for your option
Color Customized, standard of RAL6011





Product Advantage



1,Optimized lobe curve is adopted for reducing blower’s internal leakage,improving blower’s efficiency and reducing running temperature.

2, After shaft’s diameter enlarged,no deformation and collision will occur under higher load pressure as the blower’s strength is improved.

3,The synchromesh gear adopts straight tooth structure for smooth operation.

4,Deep groove ball bearing of high precision and low friction factor is selected for lowering operation noise.In addition,because of large size bearing matched for enlarged shaft diameter,the bearing’s load capacity is enhanced and its service life is extended.

5,Low noise and vibration, compact and economical energy consumption.





Parameter sheet

Model Port Dia (MM) Speed Inlet airflow (m3/min)and shaft power(KW)
0.1kgf/cm2 0.2kgf/cm2 0.3kgf/cm2 0.4kgf/cm2 0.5kgf/cm2 0.6kgf/cm2 0.7kgf/cm2 0.8kgf/cm2
1000mmH2O 2000mmH2O 3000mmH2O 4000mmH2O 5000mmH2O 6000mmH2O 7000mmH2O 8000mmH2O
0.01Mpa 0.02Mpa 0.03Mpa 0.04Mpa 0.05Mpa 0.06Mpa 0.07Mpa 0.08Mpa
rpm m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW
BK9030S 250 (10") 850 63.04 31.99 60.19 40.17 58.00 48.36 56.16 56.54 54.53 64.73 53.06 72.91 　 　 　 　
1000 75.38 37.63 72.53 47.26 70.34 56.89 68.50 66.52 66.87 76.15 65.40 85.78 64.05 95.41 62.80 105.04
1150 87.72 43.27 84.87 54.35 82.68 65.42 80.84 76.50 79.21 87.57 77.74 98.65 76.39 109.72 75.14 120.80
1250 95.95 47.04 93.09 59.08 90.91 71.11 89.06 83.15 87.44 95.19 85.97 107.23 84.62 119.26 83.36 131.30
1400 108.29 52.68 105.43 66.16 103.25 79.65 101.40 93.13 99.78 106.61 98.31 117.64 96.96 133.58 95.70 147.06
1500 116.51 56.45 113.66 70.89 111.47 85.34 109.63 99.78 108.00 114.23 106.54 128.67 105.18 143.12 103.93 157.56





Structure of blower main body


0.8 Bar 132kw 10" 850-1500 Rpm 71.52-116.5m3/Min Tri Lobe Roots Blower 0





No.

Part Name

Qty.



No.

Part Name

Qty.



No.

Part Name

Qty.

1

Footing

2



9

Left end cover

1



17

Oil tank

1

2

Hexagon bolt

4



10

Round pin

4



18

Gear

2

3

Antidust seal

1



11

Casing

1



19

Key

2

4

Drive impeller

1



12

Oil seal

4



20

Axial sleeve

2

5

Bearing

2



13

Right end cover

1



21

Bearing

2

6

Driven impeller

2



14

Bolt

16



22

Bearing plate

2

7

Dust cup

1



15

Breather

1



23

Adjustable pad

several

8

Grease nipple

2



16

Bolt

8



24

Magnetic nut

1





Assembling drawing of blower package



0.8 Bar 132kw 10" 850-1500 Rpm 71.52-116.5m3/Min Tri Lobe Roots Blower 1





Standard supply of scope



1. bare shaft blower

2. pressure relieve valve

3. wafer check valve (slim type)

4. inlet silencer(with air filter)

5. outlet silencer

6. public base (with belt cover)

7. rubber flexible joint and shock pad

8. motor pulley

9. pressure gage

10. V-belt

11. bolts and nuts and other connection parts

12. electric motor



Product Applications

Our products are widely used. The company takes on keep improving our forever seeking; Satisfy customers our invariable promise as its tenet and has won high credit from the market.



0.8 Bar 132kw 10" 850-1500 Rpm 71.52-116.5m3/Min Tri Lobe Roots Blower 2
