30m3/Min Cast Iron Three Lobe Roots Blower For Pneumatic Conveying

30m3/Min Cast Iron Three Lobe Roots Blower For Pneumatic Conveying

  • 30m3/Min Cast Iron Three Lobe Roots Blower For Pneumatic Conveying
30m3/Min Cast Iron Three Lobe Roots Blower For Pneumatic Conveying
Product Details:
Place of Origin: China
Brand Name: BK
Certification: ISO9001 / ISO14001/CE
Model Number: BK6015
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Packaging Details: EXPORT WOODEN CASE
Delivery Time: 35 WORK DAYS
Payment Terms: L/C, T/T
Supply Ability: 200 PER MONTH
Contact Now
Detailed Product Description
Name: Three Lobe Roots Blower Color: White. Blue. Green
Air Capacity: 30m3/Min Main Materials: Cast Iron
Application: Pneumatic Conveying Cooling Type: Air
Discharge Bore: DN150 (6'') Type: Positive Displacement, Roots Type, Air Conveying
Blower RPM: 850-1800 Voltage&Frequency: 380V/400/415V/440V&50Hz/60Hz
Frequency: 50HZ/60HZ
High Light:

30m3/Min Three Lobe Roots Blower

,

Cast Iron Three Lobe Roots Blower

,

Pneumatic Conveying 3 lobe roots blower

BK6015 Cast Iron Three Lobe Roots Blower For Pneumatic Conveying



Features:

1. Helical type timing gears for smooth operation
2. Compact, flexibility in installation gives users more choices.
3. Integral structure of impeller superior to split structure, more stable in power transmission
4. Adopt imported oil seals made from fluoro rubber, which is of perfect wear resistance and high-temperature resistance.
5. Small vibration and economical energy consumption.

6. BK Roots Blower is a kind of product designed and manufactured according to the national standards and by the techniques introduced from America.
7. BK Roots Blower is featured with simple structure and high cubage efficiency.

Specifications:
Model BK6015
Air capacity 30m3/Min
Discharge differential pressure 50KPA
Rotary speed 1450rpm
Motor type 37KW
380/400/415/440V, 3PHASES, 50/60HZ
Motor brand Standard: Siemens Beide or Wannan motor
Installation type Standard: horizontal type.
Vertical type available for your option
Features 1. Helical type timing gears for smooth operation
2. Compact, flexibility in installation gives users more choices.
3. Integral structure of impeller and shaft avoiding shortcomings of the split structure blower
4. Adopt imported oil seals made from fluoric rubber with  great wear resistance and high-temperature resistance.
5. Low noise, low vibration and energy consumption.


Parameter:

Model Port Dia (MM) Speed Inlet airflow (m3/min)and shaft power(KW)
0.1kgf/cm2 0.2kgf/cm2 0.3kgf/cm2 0.4kgf/cm2 0.5kgf/cm2
1000mmH2O 2000mmH2O 3000mmH2O 4000mmH2O 5000mmH2O
0.01Mpa 0.02Mpa 0.03Mpa 0.04Mpa 0.05Mpa
rpm m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW
BK6015 150 (6") 850 16.66 4.61 15.65 8.08 14.89 11.00 14.23 13.94
1000 20.02 5.43 19.01 9.50 18.25 12.94 17.60 16.40 17.04 20.39
1150 23.38 6.24 22.37 10.93 21.61 14.88 20.96 18.86 20.40 23.45
1250 25.62 6.78 24.61 11.88 23.85 16.18 23.20 20.50 22.64 25.49
1400 28.99 7.60 27.98 13.30 27.21 18.12 26.56 22.96 26.00 28.55
1500 31.23 8.14 30.22 14.25 29.46 19.41 28.81 24.60 28.25 30.59
1650 34.59 8.96 33.58 15.68 32.82 21.35 32.17 27.05 31.61 33.65
1800 37.95 9.77 36.94 17.10 36.18 23.29 35.53 29.51 34.97 36.71





30m3/Min Cast Iron Three Lobe Roots Blower For Pneumatic Conveying 0

Working Principle:

Roots blower is a cubage blower, and it discharges a fixed amount of air in proportion to its rotation speed. Every rotation, there is two lobes to finish three times absorbing and dischargeing air. Compared with two lobes blower, it is of less air pulses, smaller load change, higher strength, lower noise and vibration.

Two paraller shafts have three lobes each, all the lobes keep small clearance with each other and housing inside. Every lobes rotatiomn, a certain air will be absorbed at inlet and transfeered form the housing inside surface to blower's diacharge port.

Two shafts will be turned by the timing gears, no any touching between lobes, so it can be turned at high speed without any lubrication inside. It has the following chaaracteristics: simply configuration; running smoothly;good performance stabilization. It has been widely applied in various industries.

30m3/Min Cast Iron Three Lobe Roots Blower For Pneumatic Conveying 1

Blower Structure:

30m3/Min Cast Iron Three Lobe Roots Blower For Pneumatic Conveying 2

30m3/Min Cast Iron Three Lobe Roots Blower For Pneumatic Conveying 3

30m3/Min Cast Iron Three Lobe Roots Blower For Pneumatic Conveying 4



Application:

30m3/Min Cast Iron Three Lobe Roots Blower For Pneumatic Conveying 5

30m3/Min Cast Iron Three Lobe Roots Blower For Pneumatic Conveying 6



30m3/Min Cast Iron Three Lobe Roots Blower For Pneumatic Conveying 7
