100 4 Inch Port Dia Roots Type Blower High Efficiency Low Energy Consumption

100 4 Inch Port Dia Roots Type Blower High Efficiency Low Energy Consumption

100 4 Inch Port Dia Roots Type Blower High Efficiency Low Energy Consumption
100 4 Inch Port Dia Roots Type Blower High Efficiency Low Energy Consumption
100 4 Inch Port Dia Roots Type Blower High Efficiency Low Energy Consumption
Product Details:
Place of Origin: JIANGSU, CHINA
Brand Name: BC
Certification: ISO9001 / ISO14001
Model Number: BC5006
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 1090-1800 per set
Packaging Details: export wooden case
Delivery Time: 4 weeks
Payment Terms: L/C, T/T
Supply Ability: 100 sets per month
Contact Now
Detailed Product Description
Type: BC 5006 Port Dia: 100( 4'' )
Rpm: 850-2000 Size: 1.65*0.75*1.6 M3
Weight: 234-368 Kg Main Color: Blue
High Light:

4 inch roots style blower

,

high efficiency roots style blower

,

low energy consumption roots air blower



100 4 Inch Port Dia 3 Lobe Roots Blower High Efficiency Low Energy Consumption





1 Company brief



B-Tohin Machine ( Jiangsu ) Co.,Ltd. takes on keeping improving our forever seeking; satisfy customers our



invariable promise as its tenet and has won high credit from the market. The company successfully got the



cerficate of high-tech enterprise.



100 4 Inch Port Dia Roots Type Blower High Efficiency Low Energy Consumption 0  100 4 Inch Port Dia Roots Type Blower High Efficiency Low Energy Consumption 1





2 Main characteristics



(1) Optimized lobe curve is adopted for reducing blower's internal leakage, improving blower's efficiency



and reducing running temperature.



(2) After shaft's diameter enlarged, no deformation and collision will occur under higher load pressure as



the blower's strength is improved.



(3) The synchromesh gear adopts straight tooth structure for smooth operation.



(4) Deep groove ball bearing of high precision and low friction factor is selected for lowering operation



noise. In addition, because of larger size bearing matched for enlarged shaft diameter, the bearing's load



capacity is enhanced and its service life is extended.



(5) Low noise and vibration, compact and economical energy consumption.



100 4 Inch Port Dia Roots Type Blower High Efficiency Low Energy Consumption 2





3 Blower working principle



Roots blower is a cubage, and it discharges a fixed amount of air in proportion to rotation speed. Two



parallel shafts have three lobes each, all the lobes keep small clearance with each other and housing



inside. Every lobes rotation, a certain  air will be absorbed at inlet and transferred from the housing inside



surface to blower's discharge port.



100 4 Inch Port Dia Roots Type Blower High Efficiency Low Energy Consumption 3



Two shafts will be turned by timing gears, no any touching between lobes, so it can be turned at high speed



without any lubrication inside, It has the following characteristics: simply configuration; running smoothly;



good performance stabilization. It has been widely applied in various industries.



100 4 Inch Port Dia Roots Type Blower High Efficiency Low Energy Consumption 4



4 Technology parameter sheet



Type port dia speed different pressure,air flow and power
10kpa 20kpa 30kpa 40kpa 50kpa 60kpa 70kpa 80kpa
      M3/MIN KW M3/MIN KW M3/MIN KW M3/MIN KW M3/MIN KW M3/MIN KW M3/MIN KW M3/MIN KW
BC 5006 100(4'') 850 4.60 1.48 4.19 2.49 3.87 3.77 3.61 4.33 3.38 5.32 3.18 6.31
100 5.58 1.74 5.17 2.92 4.86 4.43 4.60 5.09 4.37 6.26 4.16 7.43
1150 6.56 2.00 6.16 3.36 5.84 5.10 5.58 5.85 5.35 7.20 5.15 8.54 4.95 9.64
1250 7.22 2.18 6.81 3.65 6.50 5.54 6.23 6.36 6.01 7.82 5.80 9.28 5.61 10.48 5.21 11.84
1350 7.87 2.35 7.47 3.95 7.15 5.98 6.89 6.87 6.66 8.45 6.46 10.03 6.26 11.31 5.88 12.79
1500 8.86 2.61 8.45 4.39 8.14 6.65 7.87 7.63 7.64 9.39 7.44 11.14 7.24 12.57 6.88 14.21
1600 9.51 2.79 9.11 4.68 8.79 7.09 8.53 8.14 8.30 10.01 8.10 11.88 7.90 13.41 7.56 15.16
1750 10.50 3.05 10.09 5.12 9.78 7.76 9.51 8.91 9.28 10.95 9.08 13.00 8.88 14.67 8.56 16.58
1850 11.15 3.22 10.75 5.41 10.43 8.20 10.17 9.42 9.94 11.58 9.74 13.74 9.54 15.50
2000 12.14 3.48 11.73 5.85 11.41 8.86 11.15 10.18 10.92 12.52 10.72 14.85 10.52 16.76
