65 2.5 Inch Port Dia High Pressure Roots Blower Tri Lobe Low Noise

65 2.5 Inch Port Dia High Pressure Roots Blower Tri Lobe Low Noise

  • 65 2.5 Inch Port Dia High Pressure Roots Blower Tri Lobe Low Noise
65 2.5 Inch Port Dia High Pressure Roots Blower Tri Lobe Low Noise
Product Details:
Place of Origin: JIANGSU, CHINA
Brand Name: BC
Certification: ISO9001 / ISO14001
Model Number: BK
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 1290-1570 / SET
Packaging Details: export wooden case
Delivery Time: 25 working days
Payment Terms: L/C, T/T
Supply Ability: 100 sets per month
Contact Now
Detailed Product Description
Type: BC5003 Port Dia: 65 ( 2.5'' )
Rpm: 850-2000 Pressure: 10-80 Kpa
Color: Blue Air Flow: 1.72-7.15 M3 / Min
High Light:

850 rpm high pressure roots blower


low noise high pressure roots blower


high pressure tri lobe roots blower

65 2.5 Inch Port Dia Tri Lobe Roots Blower / Lobe Type Blower Low Noise


B-Tohin Machine ( Jiangsu ) Co.,Ltd. is a Sino- foreign joint venture which founded in November 1994. It is


located in the Industrial Park for Environmental Science & Technology, Yixing, China, one of the State High-


Tech. The company is working on producing and selling HC low noise rotary blower, threelobes roots blower,


cacuum pump, and centrifugal blower, air bearing turbo blower, it also sells related products, such as


submersible pump. During the production, the company addopts the advanced equipments and technology


overseas, and using advanced quality management type to manage the company. All the products are widely


used in environmental protection, electricity, irrigation works, chemical industry, construction, food supplies,


gas transportation and so on.



2 Scope of application


(1) Sewage treatment works: the aeration tank provides oxygen




(2) Chemical plants: use air to transport raw meterial and products




(3) Cement factory: transport cement by air




(4) Power plant: desulfurization equipment provides oxygen





3 Main characteristics


(1) Optimized lobe curve is adopted for reducing blower's sfficiency and reducing running temperature.


(2) After shaft's diameter enlarged, no deformation and collision will occur under higher losd pressure as


the blower's strengh is improved.


(3) The synchromesh gear adopts straight tooth structure for smooth operation.


(4) Deep groove ball bearing of high precision and low friction factor is selected for lowering operation


noise, In addition, because of larger size bearing matched for enlarged shaft diameter, the bearing's load


capacity is enhanced and its servise life is extended.


(5) Low noise and vibration, compact and economcial energy consumption.


65 2.5 Inch Port Dia High Pressure Roots Blower Tri Lobe Low Noise 0



4 Blower working principle


Roots blower is a cubage blower, and it discharges a fixed amount of air in proportion to its ratation speed.


Every ratation, there is two lobes to finish three times absorbing and discharging air. Compared with two


lobes blower, it is of less air pulses, smaller load change, higher strength, lower noise and vibration.


65 2.5 Inch Port Dia High Pressure Roots Blower Tri Lobe Low Noise 1

Two parallel shafts have three lobes each, all the lobes keep small clearance with each other and housing


inside. Every lobes ratation, a certain air will be absorbed at inlet and transferred from the housing inside


surface to blower's discharge port.


Two shafts will be turned by the timing gears, no any touching between lobes, so it can be turned at high


speed without any lubrication inside. It has the following charactieristics: simply configuration; running


smoothly; good performance stabilization. It has been widely applied in various industries.



5 Technical parameters


Type Port dia Speed Pressure / Air flow/ Motor power
10Kpa 20Kpa 30Kpa 40Kpa 50Kpa 60Kpa 70Kpa 80Kpa
air flow / power air flow / power air flow / power air flow / power air flow / power air flow / power air flow / power air flow / power
BC5003 65(2.5'') 850 2.67/0.95 2.39/1.58 2.19/2.40 2.01/2.72 1.86/3.31 1.72/3.90
1000 3.25/1.12 2.98/1.85 2.77/2.83 2.60/3.20 2.44/3.89 2.31/4.59
1150 3.84/1.29 3.56/2.13 3.36/3.25 3.18/3.68 3.03/4.48 2.89/5.28 2.76/6.27
1250 4.23/1.40 3.95/2.32 3.75/3.53 3.57/4.00 3.42/4.87 3.28/5.74 3.15/6.81
1350 4.62/1.52 4.34/2.50 4.14/3.82 3.96/4.32 3.81/5.25 3.67/6.19 3.54/7.36 3.43/8.30
1500 5.20/1.69 4.93/2.78 4.72/4.24 4.55/4.80 4.39/5.84 4.26/6.88 4.13/8.17 4.01/9.22
1600 5.59/1.80 5.32/2.97 5.11/4.52 4.94/5.11 4.78/6.23 4.65/7.34 4.52/8.72 4.40/9.83
1750 6.18/1.97 5.91/3.24 5.70/4.95 5.52/5.59 5.37/6.81 5.23/8.03 5.10/9.54 4.99/10.75
1850 6.57/2.08 6.30/3.43 6.09/5.23 5.91/5.91 5.76/7.20 5.62/8.49 5.50/10.08 5.38/11.31
2000 7.15/2.25 6.88/3.71 6.67/5.65 6.50/6.39 6.35/7.78 6.21/9.18 6.08/10.90 5.96/12.29
