Professional Manufacturer of Various Kinds of Blowers
 |
| Place of Origin: | China |
| Brand Name: | BK |
| Certification: | ISO9001 / ISO14001/ISO45001 |
| Model Number: | BK7011 |
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | USD 4200- USD 5870 |
| Packaging Details: | wooden case |
| Delivery Time: | 25 work days |
| Supply Ability: | 200 sets per month |
| Name: | Three Lobe Roots Blower | Material: | Cast Iron |
|---|---|---|---|
| Air Volume: | 25.8m3/min | Pressure: | 50Kpa |
| Motor Power: | 37KW | Outlet Size: | DN150(6") |
| Blower RPM: | 1500 | Voltage&Frequency: | 380/400/415/440V, 3PHASES, 50/60HZ |
| Application: | Water Treatment,Wastewater Treatment,Aquaculture And Fish Farming | FORM E: | Yes |
| Colour: | Customized Colour | Package: | Export Special Wooden Case & Moisture-proof Plastic Film |
| High Light: | water treatment three lobe roots blower,BK series three lobe roots blower,water treatment 3 lobe roots blower |
||
Such as:
Water treatment: Roots blowers find applications in water treatment facilities for processes such as aeration in water and wastewater treatment, ozone generation for disinfection, and providing air for dissolved air flotation systems.
Wastewater treatment: Roots blowers are commonly used in wastewater treatment plants for aeration purposes. They provide the necessary air supply for the biological treatment processes, such as activated sludge systems, where microorganisms break down organic matter in the wastewater.
Aquaculture and fish farming: Roots blowers are utilized in aquaculture and fish farming systems for aeration and oxygenation of water. They help maintain optimal dissolved oxygen levels for aquatic organisms, promoting their growth and survival.
China products/suppliers.Ce, ISO9001, SGS Approved Roots Blower 10-80kpa Roots Type Blower BK7011
About BK Three Lobes Roots Blower
BK series roots blower, with the intergral structure of impeller and shaft, has a wide application in environmental protection, electric power, architecture, gas supply and etc.
Main Chrarcteristics:
1) Working smoothly as helical timing gears is adopted.
2) It is flexible mounting ways because of the same structure in inlet and outlet.
3) It adopts more reasonable bearing structure, which can incresase the bearing operation life.
4) It is low noise, vibration and energy consumption.
Specifications:
| Model | BK7011 |
| Air capacity | 9.66m3/Min-30.56m3/Min |
| Discharge differential pressure | 10-80KPA |
| Rotary speed | 700rpm-1500rpm |
| Motor type | 5.5KW-55KW 380/400/415/440V, 3PHASES, 50/60HZ |
| Motor brand | Standard: Wannan motor Siemens and ABB motor for your option |
| Installation type | Standard: horizontal type. Vertical type available for your option |
| N.W. of blower without motor | 475 kg |
| Packing size Approx. | 1.82*1.22*2.02m (length*width*height) |
| Features |
1. Helical type timing gears for smooth operation |
Features:
1. Helical type timing gears for smooth operation
2. Compact, flexibility in installation gives users more choices.
3. Integral structure of impeller superior to split structure, more stable in power transmission
4. Adopt imported oil seals made from fluoro rubber, which is of good wear resistance and high-temperature resistance.
5. Small vibration and economical energy consumption.
Working Principle
Roots blower is a cubage blower, and it discharges a fixed amount of air in proportion to its rotation speed. Every rotation, there is two lobes to finish three times absorbing and dischargeing air. Compared with two lobes blower, it is of less air pulses, smaller load change, higher strength, lower noise and vibration.
Two paraller shafts have three lobes each, all the lobes keep small clearance with each other and housing inside. Every lobes rotatiomn, a certain air will be absorbed at inlet and transfeered form the housing inside surface to blower's diacharge port.
Two shafts will be turned by the timing gears, no any touching between lobes, so it can be turned at high speed without any lubrication inside. It has the following chaaracteristics: simply configuration; running smoothly;good performance stabilization. It has been widely applied in various industries.
FAQ
1. What's the information should I provide when inquiry?
A: Air capacity
B: Pressure
C: Application
D: Use environment(Temperature, atmospheric pressure)
E: Do you need motor?
Or other specials you give us will be more appreciated.
2. What is your warranty?
Our warranty is 12 months after received the roots blower. During the warranty period, replace the damaged parts for free of charge. Out warranty period, to provide timely, high-quality technical services and price concessions spare parts to ensure continuous safe and high-quality equipment operation.
3. How long is the service life of roots blower?
In normal use environment
A- Service life of blower is more than 10 years.
B- Service life of Impeller is more than 60, 000 hours.
C- Service life of bearing is more than 50, 000 hours.
D- Service life of gear is more than 60, 000 hours.
4. What is your terms of packing?
A: Generally, we pack our goods in Fumigation Free Plywood Case. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
5. How does your factory control product quality?
We have quality inspection department. Before sending out product, we check each product. If there is quality problem, we will produce new one.
6. What are your terms of payment?
1. TT 30% AS THE ADVANCE PAYMENT AND TT 70% AFTER INSPECTION BEFORE SHIPPING.
2.100% IRREVOCABLE L/C AT STGHT.
