104.23m3/Min -55kpa 160kw Roots Blower Vacuum Pump

104.23m3/Min -55kpa 160kw Roots Blower Vacuum Pump

  • 104.23m3/Min -55kpa 160kw Roots Blower Vacuum Pump
  • 104.23m3/Min -55kpa 160kw Roots Blower Vacuum Pump
104.23m3/Min -55kpa 160kw Roots Blower Vacuum Pump
Product Details:
Place of Origin: China
Brand Name: BK
Certification: ISO9001/ISO14001
Model Number: BV250H
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export standard wooden caseAbout BKW BKW series roots blower inherits the design of BK series. It adopts water cooling in bearing cover, which can lower the temperature of bearing so as to prolong the bearing’s service life and enable higher pressure appli
Delivery Time: 5 to 20 working days, depends on order amount and specification
Payment Terms: L/C, T/T
Supply Ability: 80 SETS per month
Contact Now
Detailed Product Description
Type: Vacuum Sauction, Roots Type Air Capacity: 69.85-105.14m3/min
Discharge Differential Pressure: -10KPA - -55KPA Motor Power: 110-160KW
Discharge Bore: DN300(12") Cooling Type: Air
Driven Type: Motor Driven, Connected By Belt And Pulley
High Light:

160kw Roots Blower Vacuum Pump

,

105.14m3/Min Roots Blower Vacuum Pump

,

-55kpa Roots Blower Vacuum Pump



DN300 large capacity Roots negative pressure blower, small compact size, 69.85-105.14m3/min,-10KPA to -55KPA, 110-160KW



About BV300H Vacuum Blower



BK300H vacuum blower is a kind of displacement Roots type air pump. It can reach -55KPA vacuum pump.  It is widely used for vacuum air conveying and if featured of stable performance and excellent volumetric efficiency.




Specifications


Model

BV300H

Air capacity

69.85-105.14m3/min

Discharge differential pressure

-10   ~   -55KPA

Rotary speed

1175-1650rpm

Motor type

110-160KW

380/400/415/440V, 3PHASES, 50/60HZ

Motor brand

Standard: Siemens Beide or Wannan motor

Siemens and ABB motor for your option

Installation type

Standard: vertical type

N.W. of blower without motor

1680kg




Parameter sheet

104.23m3/Min -55kpa 160kw Roots Blower Vacuum Pump 0

104.23m3/Min -55kpa 160kw Roots Blower Vacuum Pump 1





Assembling drawing of blower package

104.23m3/Min -55kpa 160kw Roots Blower Vacuum Pump 2



Dimension size

104.23m3/Min -55kpa 160kw Roots Blower Vacuum Pump 3



104.23m3/Min -55kpa 160kw Roots Blower Vacuum Pump 4


Standard supply of scope


1. blower main body

2. vacuum safety valve

3. inlet silencer

4. outlet silencer

5. public base (with belt cover)

6. rubber flexible joint and shock pad

7. blower pulley

8. pressure gauge

9. belt

10. bolts and nuts and other connection parts

11. motor
