XTB 400HP Air Turbo Suspension Centrifugal Blower 149-245 M³/min Flow Rate

 Product Brief

An air suspension bearing centrifugal blower is a highly efficient, low-maintenance fluid transportation device that combines air suspension bearing technology with centrifugal blower design.

 It is widely used in wastewater treatment, chemical, food, pharmaceutical, and power industries.

Air Suspension Bearing Technology

•  Contactless Suspension: High-pressure air forms a micron-level air film between the rotor and bearing, enabling complete suspension of the rotor without mechanical friction, eliminating wear issues common in traditional bearings (e.g., ball bearings).

•  Active Control: Sensors monitor rotor position in real-time, dynamically adjusting air film pressure to ensure operational stability, with speeds reaching tens of thousands of RPM.

•  Advantages: No lubrication required, oil-free operation, low vibration, and an ultra-long lifespan .

Product Components

  Advantages of XTB Blower

(1) Energy-saving, high efficiency
Air bearing turbo centrifugal blower adopts air foil bearings, direct-connection technology, high efficiency impeller and motor. No additional friction will occur, and motor power consumption is automatically adjusted according to the output airflow capacity (adjustable range 20-100%), so the energy-saving effect is remarkable.

(2) Low noise
Adopt air bearing and direct-connection way without mechanical contact. Noise is lower than 80dB- @ 1.5m, so there’s no need to install acoustic enclosure.

(3) No oil, no vibration
Air quality reaches ISO 8573-1 0 grade without vibration, so anti-vibration work is not required.

(4) Convenient maintenance
Without gearbox and oil-lubricated bearing of traditional blowers, high and new technology is introduced for convenient maintenance



Typical Applications

• 1,Wastewater Treatment: Aeration oxygenation (e.g., A2O process), replacing traditional Roots blowers with significant energy savings.

•

• 2,Food/Pharmaceutical: Oil-free air prevents product contamination, complying with GMP standards.

•

• 3,Chemical/Electronics: Transporting corrosive or clean gases, with material options like stainless steel or anti-corrosion coatings.

•

• 4,New Energy: Air supply for fuel cells, requiring high-precision flow control.
