Cast Iron Rotary Air Blowers HC-50S for underground sewage treatment

Cast Iron Rotary Air Blower HC-50S for underground sewage treatment

About HC


Originated in Japan (Tohin Shoji Co., Ltd., B-Tohin has been producing this blower since its establishment in 1994 by advanced technology and equipment from Japan. HC blower is featured of exquisite structure, low noise and stable performance, and has been widely used in Japan and in China.

.


Specifications

Applications

• Wastewater aeration
• Mixing and aerating of hospital and laboratory waste products
• Conveying papers in offset printing operations
• Agitation and aeration for plating tanks and waste water
• Air supplier for plastic welding and blowing
• For mist spray of burner and in glass industry and others

Features

• Compact, low noise and economical energy consumption. (It adopts the principle of air compressed by revolving movement. Therefore, although compact, the rotary  blowers display their powerful discharged capacity, low noise, litter energy consumption that can't be surpassed by other competitors.)

  ---



• Stable operation, simple installation. (In the case of small types, the blower can be conveniently installed and mere vibration produced if placed correctly, not requiring any other anti-vibration device.)

  ---



• Resisting load changes, securing fixed air flow rate (For instance, if a rotary blower is used for sanitary treatment in the aeration tank, almost no air flow rate is decreased even if load becomes large due to the change in the pressure inside tank.)

  ---



• Air chamber equipped for dispersing air smoothly. (All models are provided with an air chamber, resulting in being free from air pulsation and air dispersed smoothly.)

  ---



• Superior material, ingenious structure, remarkable

  ---



• performance (All parts of the blowers are made of good material and are fine designed and manufactured. It is durable in use and free of trouble and deterioration of performance after a long time use.)

  ---



• Simple maintenance, rare malfunctions, long using life (The low speed of blower ensures small abrasion and long life.)

Working Principle

The blower is so designed and constructed that air is sucked, compressed and discharged  repeatedly while vanes protruding from the grooves of rotor are coming in and out by revolution of a rotor (rotating body)   set eccentrically inside the cylinder diameter. A minimum required quantity of oil is dropped to an oil dropping nozzle, then dropped into the cylinder always while operating in order to make lubrication for the purpose of preventing heat and noise from generating. In the same time, circumfluence of air in cylinder is avoided.

Standard supply of scope

HC Rotary blower's structure is exquisite. It mainly consists of motor, air filter, blower body, air chamber, base (and oil tank) and oil dropping nozzle.
