High Efficiency Multistage Industrial Centrifugal Blower , vacuum centrifugal fan

High Efficiency Multistage Industrial Centrifugal Blower , vacuum centrifugal fan

High Efficiency Multistage Industrial Centrifugal Blower , vacuum centrifugal fan
High Efficiency Multistage Industrial Centrifugal Blower , vacuum centrifugal fan
High Efficiency Multistage Industrial Centrifugal Blower , vacuum centrifugal fan
Product Details:
Place of Origin: China
Brand Name: BK
Certification: ISO9001/ISO14001
Model Number: D80-(1.4-1.8)
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 20-40 working days, depends on order amount and specification
Payment Terms: L/C, T/T
Supply Ability: 10 SETS per month
Contact Now
Detailed Product Description
Air Capacity: 80m³/min Motor Power: 90-160KW
Discharge Bore: DN300(12”) Cooling Type: Water
Driven Type: Coupling Application: Sewage Treatment, Smelting Furnace, Coal Preparation Plant, Mine Floatation, Chemical Gas, Vacuum Industry, And Other Gas Conveying, Etc.
Inlet Pressure: 98 Kpa Outlet Pressur: 39.2-78.5 Kpa
Inlet Tem.: 20℃
Highlight:

multi stage centrifugal blowers

,

high pressure centrifugal blower

Efficiency Multistage Centrifugal Blower, vacuum use centrifugal fan



Introduction



D type Multi-stage Centrifugal Blowers are widely applied to  sewage treatment, smelting furnace, coal preparation plant, mine floatation, chemical gas, vacuum industry, and other gas conveying, etc.





Specifications



Model Inlet Flow m³/min Inlet Pressure kPa Inlet Temperature℃ Set-up Pressure Speed r/min Shaft Power kW Motor Power kW Weight(Excluding Motor)KG
kPa mmH₂O
D80-1.4 80 98 20 39.2 4000 2950 71 90 2600
D80-1.5 80 98 20 49 5000 2950 87 110 2800
D80-1.6 80 98 20 58.8 6000 2950 104 132 3100
D80-1.7 80 98 20 68.6 7000 2950 110 132 3700
D80-1.8 80 98 20 78.5 8000 2950 117 160 3900





Features

.

1. low noise level. It is machined with advanced CNC machining centers, operating smoothly with low vibration, producing low noise level.



2. good treatment in sealing, no medium leakage from the blower casing.



3. energy saving and in high quality, long service life.



4. equipped with famous brand accessories, reliable quality and stable operating performance.



High Efficiency Multistage Industrial Centrifugal Blower , vacuum centrifugal fan 0





Structure of blower main body



High Efficiency Multistage Industrial Centrifugal Blower , vacuum centrifugal fan 1









Assembling drawing of blower package



High Efficiency Multistage Industrial Centrifugal Blower , vacuum centrifugal fan 2



Standard supply of scope



1. Blower main body

2. Inlet muffler (with air filter)

3. Public base for motor and blower(including coupling cover)

4. Inlet manual butterfly valve

5. Motor

6. Pressure gauge

7. Mounting bolts and connection accessories

8. Check valve
