DN32 1.5KW HC-401S Rotary Air Blower for family sewage Aeration

HC-401S Rotary Air Blower, air blower, DN32, 1.5KW family sewage areator

About HC


HC blower is a special type blower. It is composed of motor, air filter, blower main body, air chamber, base and oil tank and oil dripping nozzle.  HC blower is originated in Japan in 1950. Since established in 1994, B-Tohin has been specialized in blower industry by studying the advanced technology of Tohin Shoji.

And after more than 20 year's marketing, B-Tohin's HC blower has been widely used in China and in the world market.

Specifications

Applications

• Wastewater aeration
• Mixing and aerating of hospital and laboratory waste products
• Conveying papers in offset printing operations
• Agitation and aeration for plating tanks and waste water
• Air supplier for plastic welding and blowing
• For mist spray of burner and in glass industry and others
• new rural construction sewage treatment station

Features

• Compact, low noise and economical energy consumption. (It adopts the principle of air compressed by revolving movement. Therefore, although compact, the rotary  blowers display their powerful discharged capacity, low noise, litter energy consumption)

  ---



• Stable operation, simple installation. (In the case of small types, the blower can be conveniently installed and mere vibration occurred if placed correctly, not requiring any other vibration-proof device.)

  ---



• Resisting load changes, securing fixed air flow rate (For instance, if a rotary blower is used for sanitary treatment in the aeration tank, almost no air flow rate is decreased even if load becomes large due to the change in the pressure inside tank.)

  ---



• Air chamber equipped for dispersing air smoothly. (All models are provided with an air chamber, resulting in being free from air pulsation and air dispersed smoothly.)

  ---



• Good material, different structure designed in Japan, remarkable

  ---



• performance (All parts of the blowers are made of qualified material and are fine designed and manufactured. It is durable in use and free of trouble and deterioration of performance after a long time use.)

  ---



• Simple maintenance, rare malfunctions, long using life (The low speed of blower ensures small abrasion and long life.)

Working Principle

The blower is so designed and constructed that air is sucked, compressed and discharged  repeatedly while vanes protruding from the grooves of rotor are coming in and out by revolution of a rotor (rotating body)   set eccentrically inside the cylinder diameter. A minimum required quantity of oil is dropped to an oil dropping nozzle (imported from Japan), then dropped into the cylinder always while operating in order to make lubrication for the purpose of preventing heat and noise from generating. In the same time, it is free of circumfluence of air in cylinder.

Standard supply of scope

HC Rotary blower's structure is exquisite. It mainly consists of air chamber, electric motor, air filter, blower main body, base (and oil tank), oil dropping nozzle, pulley and other connection parts.
